Steering
!

Steering box complete - Army reco

This Steering box was is reconditioned by the Australian army with all new parts. As new.

Replaces steering boxes in all models 1954-58, but early models with central dipswitch and horn will need those switches relocated.

Rocker shaft - steering box

Genuine NOS

 271372

one only

Steering worm shaft - new

new wormshaft for series 1 steering box, suit recirc. ball type box (1955-58) Suit RHD, not LHD.

*check the length of your shaft if you are unsure of your steering box*

Seal for wiring harness on bottom of steering box 1948-55

This is the seal that fits into a conical section at the bottom of the steering box.

Washer for sealing ring Genuine NOS 265489

suit 86 and 107 steering boxes









s201a

Steering Relay Box - Genuine NOS

New steering relay, be careful removing the old one, they are usually rusted in pretty solid, you can make up a frame and use a bottle jack to press it out, but make sure the frame is close to the relay at the top or you might just crush the chassis. Pour some thin lubricant like diesel to soak from around the top. 232693 NRC1269

Steering Relay Box - Genuine used

Used steering relay, suit all models 1948-58

Steering Relay Cone Bush - 1948-58

This is the common wear part. steering relay cone bush, suit all models 1948-58

you need two of these kits to rebuild a relay. (2 sets shown)

230758

Limit 4 per customer

Steering Relay Seal kit - Genuine

steering relay seals and gaskets, suit all models 1948-58

Steering Relay Shaft - NOS

steering relay shaft, suit all models 1948-58

230762









Steering Ball Joint - Left

this balljoint has a left hand thread, and a safety shoulder where the clamp squeezes the tube, don't use the incorrect later series balljoints!

Steering Ball Joint - Right

this balljoint has a Right hand thread, and a safety shoulder where the clamp squeezes the tube, don't use the incorrect later series balljoints!

Steering Joint rubber boots and springclips x6

Small type rubber boots to fit ball joints 1948-58 models. This is a kit to renew all 6 joints

Steering track rod used

This is the long metal tube that connects the front wheels

Steering drag link rod used

This is the long metal tube that connects the relay to the front wheel.

Steering Ball Joint clamp - cast type - used

genuine used 218511

Steering Ball Joint clamp - steel type - used

replaces 218511









Steering Box drop arm 1948-53 used

sandblasted and inspected OK, this is the drop arm from the steering box to the ball joint.

Steering Box drop arm 1956-58 used

sandblasted and inspected OK, this is the straight drop arm from the steering box to the ball joint. You can also used the curved type which is a little cheaper.

Steering Box drop arm 1956-58 curved used

sandblasted and inspected OK, this is the drop arm from the steering box to the ball joint.

Steering Relay bottom arm 1948-58 used

sandblasted and inspected OK, this is the drop arm from the steering relay in the chassis to the ball joint. (pic example only)

270702

Steering Relay bottom arm 1948-58 reproduction



270702

Steering Relay top arm 1948-58 used

sandblasted and inspected OK, this is the top arm from the steering box to the ball joint. (pic example only)









Steering wheel centre cover - used

Suit 55-58 models

Steering box support bracket
